SBM
SLOW BLOW
Product Description

Voltage Rating : DC58V or less

Interrupting Rating: 2000A @58VDC

Operating Temperature Range: -40℃ to +125℃

Complies with ISO 8820-6

Materials :
1. Copper Alloy
2. Ceramic
3. Plastic

※ Characteristics of fuses according to use conditions may change.

Purchase :
Product Introduction

Time-Current Characteristics

Test Current Opening Time
40A~250A 300A~500A 600A
Min. Max. Min. Max. Min. Max.
75% --- --- 4 hrs. --- 4 hrs. ---
100% 4 hrs. --- --- --- --- ---
135% 120 s 1800 s --- --- --- ---
200% 1 s 15 s 1 s 15 s 1 s 40 s
350% 0.3 s 5 s 0.5 s 5 s 0.5 s 5 s
500% --- --- --- --- 0.1 s 1 s
600% 0.1 s 1 s 0.1 s 1 s --- ---

Fuse Catalogue

Item No. Ampere
SBM 40 40 A
SBM 60 60 A
SBM 80 80 A
SBM 100 100 A
SBM 125 125 A
SBM 150 150 A
SBM 175 175 A
SBM 200 200 A
SBM 225 225 A
SBM 250 250 A
SBM 300 300 A
SBM 350 350 A
SBM 400 400 A
SBM 500 500 A
SBM 600 600 A
